ASME SB-265 Standard Specification For Titanium And Titanium Alloy Sheet And Plate

Ask Lasest Price
Brand Name :	DELTA
Model Number :	GR1 GR2 GR3 GR4 GR5 GR7
Certification :	ISO
Price :	40-45 USD/Kg
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3 Ton per week
Delivery Time :	5 - 12 days based on the quantity

Add to Cart

Product Details
Company Profile

ASME SB-265 Standard Specification For Titanium And Titanium Alloy Sheet And Plate

ASME SB-265 | Standard Specification for Titanium and Titanium Alloy Sheet and Plate

Grade	TA1, TA2, TA3, TA4, TA10, TA15, TA17, GR1, GR2, GR3, GR4, GR5, GR7, GR9, GR11, GR12
Size	T(3.0mm~120mm)W(800mm~2200mm)L T(0.4mm~3mm)W(1500mm max)L
Standard	ASTM B 265, ASME SB265 AMS491
Application	Chemical, industry, sports etc.
Feature	High corrosion resistance, low density, good thermal stability
Surface	Bright, Polished, Pickling, Acid cleaning, Sandblasting
Quality and test	Hardness test, Bending test, Hydrostatic etc.
Finish	Roll-up(Hard)
Surface	Polished

AVAILABLE SIZES:

Sheet is 0.3mm to 4.1mm thick, up to 1500mm width cold roll
Plate is 4.1 mm to 100mm thick, up to 3000mm width hot roll

PROCESSING
Hot rolling and cold rolling

PROCESSING STANDARD:
ASME SB/B265, AMS 4911, AMS 4919, AMS 4914, ASTM F67, ASTM F136, ASTM F1341, ISO 5832-2, MIL-T-9046

EXAMPLE APPLICATIONS:

Fire wall, driver protection, valve covers, bell housings, driveshaft tunnels, brake backing plates, heat shields, rocker shaft stands, jewelry etc

STANDARD	CHEMICAL COMPOSITION (weight %, max or range)											MECHANICAL PROPERTIES (min)
ASTM B265	UNS No	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Tensile	Yield	El.	Red.
ASTM B265	UNS No	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Mpa	Mpa	%	%
GR 1	R50250	0.03	0.08	0.015	0.2	0.18						240	138	24	30
GR 2	R50400	0.03	0.08	0.015	0.3	0.25						345	275	20	30
GR 3	R50550	0.05	0.08	0.015	0.3	0.35						450	380	18	30
GR 4	R50700	0.05	0.08	0.015	0.5	0.4						550	483	15	25
GR 5	R56400	0.05	0.08	0.015	0.4	0.2	5.5-6.75	3.5-4.5				895	828	10	25
GR 7	R52400	0.03	0.08	0.015	0.3	0.25			0.12-0.25			345	275	20	30
GR 9	R56320	0.03	0.08	0.015	0.25	0.15	2.5-3.5	2.0-3.0				620	483	15	25
GR 12	R53400	0.03	0.08	0.015	0.3	0.25				0.2-0.4	0.6-0.9	483	345	18	25
GR 23	R56401	0.03	0.08	0.0125	0.25	0.13	5.5-6.5	3.5-4.5				828	759	10	15

TITANIUM MATERIALS SUPPLY SCOPE
TITANIUM GRADE	UNS NO.	WIRE	BAR	SHEET	PLATE	TUBE	PIPE	FITTING	FORGING	FASTENER
Ti Grade 1	R50250	√	√	√	√	√	√	X	√	√
Ti Grade 2	R50400	√	√	√	√	√	√	√	√	√
Ti Grade 3	R50550	√	√	√	√	X	X	X	√	√
Ti Grade 4	R50700	√	√	√	√	X	X	X	√	√
Ti Grade 5 (6Al 4V)	R56400	√	√	√	√	X	X	X	√	√
Ti Grade 7 (0.2Pd)	R52400	√	√	√	√	√	√	√	√	√
Ti Grade 9 (3Al 2.5V)	R56320	√	√	√	√	√	X	X	√	√
Ti Grade 11	R52250	√	√	√	√	√	√	X	√	√
Ti Grade 12 (0.3Mo 0.8Ni)	R53400	√	√	√	√	√	√	√	√	√
Ti Grade 17	R52252	X	√	√	√	√	√	X	√	√
Ti Grade 23 (6Al 4V Eli)	R56401	√	√	√	√	X	X	X	√	√
Notes 1) √-Available, X-Unavailable
Notes 2) For other grades like Ti6Al2Sn4Zr2Mo, Ti6Al6V2Sn, Ti8Al1Mo1V, Ti6Al2Sn4Zr6Mo, Ti15V3Cr3Sn3Al, please contact us for details.
Notes 3) It may differs a little for materials in different sizes, please also contact us.

ASTM B265 ASME Sb265 Gr1 Gr2 Gr7 Titanium Plate Sheet Strips

Titanium and Alloy Products

Product name	Specifications
Titanium Rod & Bar & Ingots	Ф3mm~Ф1020mm,the maximum weight is up to 12t
Titanium Slab	(80~400)mm×(~1500)mm×(~2600)mm
Titanium Forgings	Weight per piece≤2000kg
Titanium Hot-rolled plates	(4~100)mm×(800~2600)mm×(2000~12000)mm
Titanium Cold-rolled Sheet	(0.01~4.0)mm×(800~1560)mm×( ~6000) mm
Titanium Foil / Strips	(0.01~2.0)mm×(800~1560)mm×L
Titanium Tubes / Pipes	Ф(3~114)mm×( 0.2~5)mm × (~15000)mm
Standards	GB,GJB,ASTM,AMS,BS,DIN,DMS,JIS,ГОСт
Titanium Grade	GR1,GR2,GR3,GR5,GR7,GR12 BT1-00,BT1-0,BT1-2 TA0,TA2,TA3,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4

Titanium Production Process
ASTM B265 ASME Sb265 Gr1 Gr2 Gr7 Titanium Plate Sheet Strips
Titanium Production Equipment

Welcome to conact us for titanium inquiry

ASME SB-265 Standard Specification For Titanium And Titanium Alloy Sheet And Plate
