    EN 10204-3.1 Certificate Titanium Rod GR2 GR5 Titanium And Titanium Alloy Rod Bars

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : GR1 GR2 GR3 GR4 GR5 GR7
    Certification : ISO
    Price : 40-45 USD/Kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3 Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    EN 10204-3.1 Certificate Titanium Rod GR2 GR5 Titanium And Titanium Alloy Rod Bars

    EN 10204-3.1 Certificate Titanium Rod GR2 GR5 Titanium And Titanium Alloy Rod Bars


    DescriptionTitanium bar/Titanium rod
    MaterialGr1, Gr2, Gr3,Gr4,Gr5, Gr7, Gr6,Gr9, Gr11, Gr12 ,Gr16, Gr17,Gr25 TA0,TA1,TA2,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4
    StandardASTM B265,ASME SB265,DIN17851,TiA16Zr5Mo1.5,JIS4100-2007,GB3461-2007
    MOQ1kg
    Equepment usedCNC lathes, Milling machine, Machining Center,Thread rolling machine Magnetic needle polishing machine
    PackageStandard export package,suit for all kinds of transport ,or as required.
    Application1.Based on High intensity,titanium products tensile strength can be up to 180Kg/mm².2.Titanium and titanium alloy in aviation industry, is called “space metal”; In addition,in the shipbuilding industry, chemical industry, manufacturing machinery parts,telecommunications equipment, hard alloy, etc have increasingly extensive application3.In addition, because of the titanium alloy with the human body has very good compatibility,so the titanium alloy can also be artificial bone.

    Specialist of Manufacturing Ti Gr 2 Bright Bars, Standard Size Titanium Alloy Threaded Rods Stockist, ASTM B348 Titanium Hex Bars.

    ASTM B348, B863 Titanium Alloy Round Bars Specification :

    Size : 8mm - 200mm

    Length : Random, Fix & Cut Length

    Specifications : ASTM B348 / ASME B348, ASTM B 863 / ASME SB 863.

    Dimensions : ASTM, ASME, AMS

    Form : Round, Square, Hex (A/F), Bush, Rectangle , Flat, Wire Mesh

    Finish : Bright, Polish & Black


    Titanium Gr 2 / Gr 5 Round Bars Equivalent Grades
    STANDARDWERKSTOFF NR.UNS
    Titanium Gr23.7035R50400
    Titanium Gr53.7165N56400
    Titanium Gr 2 / Gr 5 Round Bars Chemical Composition

    GradeTiCFeHNOAlV
    Ti Grade299.2 min0.1 max0.3 max0.015 max0.03 max0.25 max--
    Ti Grade590 min-0.25 max--0.2 max6 min4 min

    Titanium Gr 2 / Gr 5 Round Bars Mechanical & Physical Properties

    GradeDensityMelting PointTensile StrengthYield Strength (0.2%Offset)Elongation
    Ti Gr24.5 g/cm31665 °C (3030 °F)Psi – 49900 , MPa – 344Psi – 39900 , MPa – 27520 %
    Ti Gr54.43 g/cm31632 °C (2970 °F)Psi – 138000 , MPa – 950Psi – 128000 , MPa – 88014 %

    Packaging With the standard plastic bags inside, wooden case or as per client’s requirement.

    Production process Titanium Sponge—Compacting electrodes—Multiple melting—Titanium ingots—Machining—UT testing—Chemical composition inspection—Forged

    billets—Forged/Rolled—Annealed—-Straightening—Machining—UT testing—Visual and Dimension Inspection—UT testing—Marking—Packaging—Delivery

    Titanium bar is highly resistant to chloride-containing media, practically all salt solutions, seawater, a range of acids, organic and inorganic chemicals and gases. The high environmental resistance is primarily based on a very thin, tenacious and highly protective surface oxide film. The oxide film provides high resistance to erosion in high velocity process streams. It is non-magnetic and characterized by a high melting point, high strength-to-weight ratio and a low modulus of elasticity. We provide high quality titanium bar with competitive prices and unrivaled customer service.


    EN 10204-3.1 Certificate Titanium Rod GR2 GR5 Titanium And Titanium Alloy Rod BarsEN 10204-3.1 Certificate Titanium Rod GR2 GR5 Titanium And Titanium Alloy Rod BarsEN 10204-3.1 Certificate Titanium Rod GR2 GR5 Titanium And Titanium Alloy Rod BarsEN 10204-3.1 Certificate Titanium Rod GR2 GR5 Titanium And Titanium Alloy Rod Bars
