DIN 1.6523 Structure Alloy Steel Bars SAE8620 Round Rod 20NCD2 Alloy

Ask Lasest Price
Brand Name :	DELTA
Model Number :	SAE8620/1.6523
Certification :	ISO
Price :	612-884USD/Ton
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	20Ton per week
Delivery Time :	5 - 12 days based on the quantity
MOQ :	1 Ton

Add to Cart

Product Details
Company Profile

DIN 1.6523 Structure Alloy Steel Bars SAE8620 Round Rod 20NCD2 Alloy

Products Specification

Products Name	SEA8620 / 1.6523 Alloy Steel Round Bar
Diameter	10 - 320mm
Length	6m or custom cutting any length as request
Type	Hot Rolled
Brand	BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc
MOQ	1 Ton
Loading Port	Shanghai Port
Packing	packing by steel wire rope
Deliver time	5 - 7 days for stock materials
Other Grade	Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov, 15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo, 40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo
Standard	ASTM GB EN DIN
Application	Structure and Industrial

Regular Standard Size of our SAE8620 Round Bar in Stock

Standard Diameter

10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300

Other Alloy Steel Round Bar We Can Supply:

40CrNiMoA,4340,40CrNi2Mo,34CrNiMo6,17CrNiMo6,20CrNiMoA,8620H,35CrMo,Ⅴ40,20CrMnMo,20MnCr5,30CrNiMo8,18CrNiMo7

What is 1.6523 (AISI 8620, 20NiCrMo2) Steel Material?

1.6523 (AISI 8620, 20NiCrMo2) is an alloy steel type that is commonly used in applications that require high hardness, durability, and strength properties.

1.6523 (AISI 8620, 20NiCrMo2) steel contains elements such as nickel, chromium, molybdenum, manganese, carbon, and iron. When processed to have a hardened core, this steel provides high strength and impact resistance. Additionally, it is suitable for surface-hardening processes.

1.6523 (AISI 8620, 20NiCrMo2) steel is popular due to its high strength and durability properties. However, there are also some disadvantages to this steel. For instance, difficulties in welding processes can occur, and oxidation might take place at high temperatures. Therefore, proper application and processing are essential.

What is the Hardness Value of 1.6523 (AISI 8620, 20NiCrMo2) Steel?

The surface hardness and hardness depth of 1.6523 (AISI 8620, 20NiCrMo2) steel can be adjusted through case hardening.

What are the Mechanical Properties of 1.6523 (AISI 8620, 20NiCrMo2) Steel?

You can find the material properties of 1.6523 (AISI 8620, 20NiCrMo2) in the "Technical Details" tab. All mechanical and material properties of 1.6523 (AISI 8620, 20NiCrMo2) steel are specified within this tab.

Where is 1.6523 (AISI 8620, 20NiCrMo2) Steel Used?

1.6523 (AISI 8620, 20NiCrMo2) steel is used in various industries. For example, gears, transmissions, shafts, axles, traction control components, and many other parts used in industries like automotive, aviation, agriculture, mining, energy, and construction are made from this steel type.

What is the Price of 1.6523 (AISI 8620, 20NiCrMo2) Material?

The price of 1.6523 (AISI 8620, 20NiCrMo2) material varies depending on the product section, dimensions, and surface quality. You can access 1.6523 (AISI 8620, 20NiCrMo2) steel prices

Chemical Component and Material Code:

1.6523, AISI 8620, 20NiCrMo2

Carbon	Manganese	Molybdenum	Silicon	Phosphorus	Sulfur	Chromium	Nickel
0,17 - 0,23	0,65 - 0,95	0,15 - 0,25	Max 0,40	Max 0,025	Max 0,035	0,35 - 0,70	0,40 - 0,70

Mechanical Properties

Hardness	24-34	HRC
Tensile Strength	530	MPa
Yield Strength	385	MPa
Elongation L=5D	18	%

Physical Properties

Coefficient of Thermal Expansion	6,6	1/K * 10-6
Thermal Conductivity (20°C)	46.6	W/mK
Density	7.85	g/cm3

DIN 1.6523 Structure Alloy Steel Bars SAE8620 Round Rod 20NCD2 Alloy
